Saunum AIR L 13

Sauna Heater System

Model: AIR L 13

Certification/Global Safety Rating: UL (Underwriters Laboratories)

Room Size: 317-565 cu.ft.

Wattage Rating: 13000

Operating Voltage: 240V

Phase: Single

Amperage: 54A

Circuit Breaker: See Installation and Operation Manual

Wire Size to Power Unit: (2) #6 + N + G

Minimum Ceiling Height: 79"

Stone Capacity: 198 lbs

Stone Size: 2" - 4" (5-10 cm)

Heater Width: 19"

Heater Depth: 18.1"

Heater Height (Including Telescopic Air Intake): 72.25-95"

Heater Weight: 147 lbs

Shipping Weight with Stones: 345 lbs (157 kg)


Display Panel

Model: AIRIQ WI-FI

Certification/Global Safety Rating: UL (Underwriters Laboratories)

Type: Digital, Soft-Touch

Response: Tactile with Haptic Feedback Technology

Language Selection: 16-Languages

Wi-Fi Capability: Wi-Fi, App-Based Updates, and Operation

Notifications: Sauna is Ready, Heater Status, Open Door, and Overheating Protection

Safety Features: Admin, Screen Lock, Door Sensor, and Overheating Protection

Color: Nordic Black

Heat Equalizing Control: 3-Speed Adjustability

Width: 3.3"
Depth: .8"
Height: 4.1"

IP Rating: IP20

Minimum Temperature Setting: 104°F (40°C)

Maximum Temperature Setting: 194°F (90°C)

Duration Timer: 1 - 6 Hours

Display Panel Cable: 4-Conductor Cable (150°C), 20AWG, 15'

Door Sensor and Cable Assembly (Included with Heater): 2-Conductor Cable (150°), 20AWG, 9.83'

Door Sensor Probe: 1"L x .24" Diameter

Operating Temperature Range: -4 - 145°F (-20 - 62°C)

Programmability: Weekly Scheduling with 3 Programmable Sessions

Temperature Settings: Fahrenheit or Celsius

Region Settings: North American and European Versions

Room Temperature Sensor: (Included with Heater)

Pre-Mounted with Integrated Cable (150°C), 9.5'

Air Mixing Technology – Saunum patented air blending system mixes cold oxygen-rich air from the floor with hot oxygen-poor air off the ceiling to solve the discomfort so many associate with sauna. Whether you like it extremely hot, or just warm, Saunum delivers both in a way that heat and oxygen is felt head to toe.

European Design – With elegant black steel finish, Saunum combines Scandinavian design and quality materials. Select the the simple elegance of the Nordic black steel body.

Massive Stone Capacity – Stones are the heart of a Nordic sauna. Ample stones result in softer, more even heat, and can produce more luxurious steam. Large 265 pound stone capacity (required 8 boxes sold separately).

Himalayan Salt Reservoir – Saunum’s Himalayan salt tray is positioned within the air stream so that salt ions are propelled throughout the sauna to deliver health benefits more effectively.

Dry your Sauna – Go ahead, toss water onto the rocks! Saunum is engineered for water-tossing, and when you're done enjoying the steam, the patented fan system will conveniently help dry your sauna.

UL Certification – Safety and reliability are priorities at Saunum, and each product is engineered to exceed strict UL standards.

Available Aromatherapy - Add another sensory layer with Saunum's optional aromatherapy system, which infuses aroma into the steam to further transform your experience.

Saunum Air L Installation Manual

Saunum Air IQ Control Manual

Free Shipping to Canada.

Note: On rare occasions, remote or complex delivery areas may not qualify for this rate.

About This Delivery: This sauna heater system requires a scheduled appointment. It arrives on a wooden pallet and is encased in three-ply cardboard for solid protection. The driver is responsible for “delivery only” and will provide limited assistance at the site. Prior to shipping, we may contact customers to share shipment details and needs and discuss any extenuating delivery circumstances that may complicate or cause additional delivery expenses. Our goal is to ensure your project’s success.
